Detailed description
Technical features
|
|
SRP1000Q
|
|
Working width
|
40-1000mm
|
|
Working thickness
|
3-100mm
|
|
Working length
|
≥500mm
|
|
1#No1 abrasive belt speed
|
1-10m/s
|
|
2#No1 abrasive belt speed
|
|
|
Feed speed
|
6-30m/min
|
|
Size of abrasive belt(WxP)
|
1030x2200mm
|
|
Total motor power
|
9.74kw
|
|
Main motor
|
7.5kw
|
|
Working air pressure
|
0.55Mpa
|
|
Consumption of compressed air
|
0.5m3/min
|
|
Volume of sucked air
|
6000m3/h
|
|
Speed of sucked air |
25-30m/s
|
|
Overall dimension{LxWxH)
|
1800x2310x2000mm
|
|
Net weight
|
2000kg
|
